Delta







  arrow






DELTA Rotary Screens from GURJAR are the result of constant research and development giving a first class technological product. DELTA Screens with their Higher Thickness and Higher Open Area find universal applications for printing both large surface areas as well as outlines and details.

DELTA Screens are meant for textile printing, better colour, fine distribution, consistent colour deposition, more exact reproduction of fine details and the possibility of printing fine outlines and straight lines without any saw tooth effect DELTA Screens reflect to better printing economics due to lower dye paste consumption, higher printing speeds and lesser Screen wear with highly corrosive printing pastes.

  DELTA® 110, 125, 155 AND 185 MESH ScreenS


DELTA® 110 - The Screen - Power to Print Universal Rotary Prints

GURJAR introduced DELTA Rotary Screens in the year 1990, since then they have started receiving growing success among various type of Rotary Printers. From the whole range of DELTA Screens, the Rotary Printers have greatly appreciated the DELTA110 mesh Screens and named them Universal Screens due to the possibility of printing large blotches to very fine details with just one Screen. According to them DELTA 110 mesh Screens are ideal replacement to conventional 125 mesh Screens having following distinct advantages.

  • Easily stripable after polymerisation and printing - Not so in the case of 125 mesh
  • Pinning and Retouching made easy due to large open area and hole diameter - Not so in the case of 125 mesh

And other distinct possibilities & applications make these Screens Universal & Highly Economical Screens.

The new DELTA 110 Mesh offers universal applications as follows
:

  • Large Blotch Printing : Even colour distribution and brilliancy of shades without Moire effect.
  • Fine and Straight lines : With higher mesh and higher open area, minimizing the saw tooth effect.
  • Half Tone Printing : Clear reproduction of finest details due to high resolution of Screen.
  • Discharge Printing : Greater Dye penetrability giving better and deeper discharge effect, thanks to higher open area.


  DELTA 125 HTS & 155 HTS


Convenient Screens specially suited for half-tone printing. These Screens with adequately less O.A. % than conventional Screens used for this purpose facilitate better, sharper half-tone print effects using suitable magenta contact Screens.

DELTA Non Textile Rotary Screens

We also offer higher thickness, higher open area DELTA rotary Screens for coating and bonding applications in Screen's lengths from 900 mm to 3500 mm in 14,25,40,60,100 & 125 mesh count.


Screen
Length mm
1410 1450 1750 1980 2080 2380 2530 2650 2940 3000/3050 3500
CUTTING
Length mm
1398.5   1738.5 1968.5       2518.5 2918.5   3418.5
PRINTING
Width mm
1280 1280E 1620 1850 1850E 2250 2400 2400E 2800 2800E 3200
REPEAT MESH PKG.
µ ♥
% ♣
640 110 20 100 ± 3 18
640 125 20 100 ± 3 15
640 125 HTS 20 100 ± 3 9
640 155 HTS 20 100 ± 3 7
640 155 20 100 ± 3 13
640 185 10 95 ± 3 11

Other repeats (518, 537, 574, 609, 668, 725, 801, 820, 914, 923, 1018, 1680, 1820) on request.
Other Lengths (900 mm to 3500 mm ) on request.
We reserve the right to make suitable manufacturing changes as and when required.

ED Extra Thick Extra Durable
♥ Thickness in Microns (1 mm = 1000 Microns)
♣ Open Area in percentage
HTS Special Screen's for half tone printing

At GURJAR GRAVURES PVT. LTD. you can count on the following services:
  1. Supply of all normal type of Screens from our factory at the shortest possible delivery schedules.
  2. Our sales people will gladly provide technical advise and help you in solving your engraving problems.
  3. Our manufacturing flexibility makes it possible for our customer to obtain a non standard Screen also
