Special Coating Screens













"GURJAR" with more than 35 years of Experience in the field of Screen Making for Rotary Printing has been responsible for successful introduction of Special Coating Screen for Rotary Screen Coating for a variety of paste and substrate as per customer's requirement.

"GURJAR" Special Coating Screens have universal Coating applications and can be used not only in the textile Industry but also on varied substrates other than textiles namely paper, vinyl, plastic, open or closed in texture or any other conceivable substrate with really no end of possible applications.

You can choose suitable Special Coating Screens for your application on the basis of these 4 parameters: (1) The desired application volume (2) The nature of the substrate (3) The viscosity of the paste (4) The size of the solid particles in the paste. With these 4 parameters you can determine Mesh Count of Screens required and its Open Area. It is also advisable to select Special Coating Screens with greatest wall thickness and adequate open area to ensure stability while coating.

Using these Screens, you can apply every conceivable paste or plastisols as well as any aqueous paste, both foamed and unfoamed. Adhesives for laminates can also be applied on any substrate.

However, in the unlikely event if you are not able to find a suitable Screen for your application, then it is always possible for you to get customized Coating Screens from "GURJAR's" wide variety of Designer Galvano Screens.

Screen
Length mm
1410 1460 1750 1980 2080 2380 2650 2940 3050 3500
CUTTING
Length mm
1398.5   1738.5 1968.5     2618.5 2918.5   3418.5
PRINTING
Width mm
1280 1280E 1620 1850 1850E 2250 2400 2400E 2800 3200
REPEAT MESH PKG.
µ ♥ % ♣
640 14 01 450 40
640 25 01 200 40
640 25 01 300 33
640 25 01 400 30
640 40 01 200 35
640 40 01 300 24
640 60 01 200 18
640 60 01 160 13
640 100 01 140 17
640 125 01 140 14

Other repeats (518, 537, 574, 609, 668, 725, 801, 820, 914, 923, 1018, 1680, 1820) on request.
Other Lengths (900 mm to 3500 mm ) on request.
We reserve the right to make suitable manufacturing changes

♥ Thickness in Microns (1 mm = 1000 Microns)
♣ Open Area in percentage.

At GURJAR GRAVURES PVT. LTD. you can count on the following services:
  1. Supply of all normal type of Screens from our factory at the shortest possible delivery schedules.
  2. Our sales people will gladly provide technical advise and help you in solving your engraving problems.
  3. Our manufacturing flexibility makes it possible for our customer to obtain a non standard Screen also
